Specification
Electrical
Contact resistance 20M Ohms MAX
Insulation resistance 250M Ohms MIN @ 500DC
Withstand voltage DC1000V AC700V RMS 60Hz, IMIN
CAT6 permanent link conform to ANST/ TIA/ EIA 568B.2-10
Mechanical
PS plastic material
PC IDC material
Terminal: Phosphor bronze, TIN Gold 3U"/ 6U"/ 15U"/ 30U"/ 50U"
RJ45 contact life 750 times min
IDC life 200 times min
OD 6.0 – 9.0mm
Compact cable manager for round solid cable AWG 23-26(1/0.41 - 1/0.56mm) and stranded cable AWG 24-26(7/0.16 - 7/0.20mm)
Environmental
Storage -40°C ~ +70°C
Operation -10°C ~ +60°C
