Center Conductor: 1.02mm 25% Copper
Dielectric: 4.80 ± 0.10mm Foamed PE
Inner Shield
Foil: 17mm Bonded Foil
Braid 16x6x0.12mm Aluminum
Outer Shield Foil: 19mm Al/PT Foil
Jacket: 6.80 ± 0.10mm 65? White PVC
Electrical Properties
Spaker test: 2500V
Dielectric strength: Conductor to shield 2000VDC
Capacitance: 15.5F/FT.Nom. 50.9pF/m.Nom
Impedance: 75.0 ± 3.0 Ohms
Velocity of propagation: 84.0% Nom
DCE: Conductor: 32 Ohms/1000FT. 105 Ohms/Km
Shield: 5.3Ohms/1000FT. 17.4 Ohms/Km
SRL: 20dB(5 thru 1000MHz) 100% Swept Tested
15dB(5 thru 1000MHz) 100% Swept Tested
