Digital circuit design
Anti-tamper function
Installation base optional
Easy beams adjustment
Intelligent adjustment to the temperature
Detection method: Infrared photoelectric
Range: 30/40/60/80/100
Interruption period:50-270msec(selectable)
Frequency: Fixed
Power input: AC13.8-18V DC12-24V
Operation temperature: -25°C~+55°C
Environment humidity: 95% max
Alarm period: 2 Sec(±1)
Alignment angle: ±10°vertical,±90°horizontal
Alarm output: Form C relay (AC/DC30V 0.5A max)
Tamper switch: N.C. opens when cover is removed (receiver only)
IP: IP65
Aiming lens: Aiming hole Wall or pole
Apperance: PC Resin (Black)
